Hexagonal Combine Belts
Features
- Excellent transverse rigidity and flexibility to prevent bucking at minimum diameter settings, where Belt stress is more
- Firm gripping action with the contact area provides positive traction for precise speed control
- Higher power transmission capacity
- Longer service life
- Facilitates smooth running without excessive vibrations
- Specific Belt design for maximum longitudinal flexibility
- Temperature range: -18°C to +80°C
Constructional features
- Wear-resistant bias-cut neoprene rubberised polyester cotton fabric
- High tenacity, low stretch, specially treated polyester cords.
- Especially compounded high modulus compression rubber
Product Range
| Section | Angle (Degree) | Manufacturing Range | Length Desg. | |
|---|---|---|---|---|
| Min. (inch / mm) | Max. (inch / mm) | |||
| 50 X 22 | 30 | 1825 | 4000 | Li |
| 45 22 | 30 | 3200 | 3200 | Li |
Notes
Aramid cord construction Belts are available upon request.
Reference Standard
ISO 3410:1989/ BS 3733: 1974
Applications
Variable speed pulley drives requiring exact speed control and maximum range of speed changes, recreational equipment machine
